CE+T Modular Inverters Bravo ECI 48/230 2.4KW Power Core Inverters Part Nuaber T521730301

Name: CET Modular Inverters Bravo ECI 48230 24KW Power Core Inverters Part Nuaber T521730301
Brand: CE+T
Price: 1 USD

CE+T Modular Inverters Bravo ECI 48/230 2.4KW Power Core Inverters Part Nuaber T521730301 Manufactures

Brand Name : CE+T

Model Number : Bravo ECI 48/230 2.4KW

Certification : CE

Place of Origin : CHINA

MOQ : 5

Price : 1USD

Payment Terms : T/T

Supply Ability : In stock + within one week

Delivery Time : 7-15days

Packaging Details : 48*20*15

Brand : CE+T

Nominal voltage (AC) : 230 V

Brownout : 1600 W

Part Number : T521730301

Nominal Output power (VA) / (W) : 3000 VA / 2400 W

Dielectric strength DC/AC : 4300 Vdc

DC voltage: Nominal / range : 48 VDC / (40-60V)*

Voltage range (AC) : 150 - 265 V

Contact Now

The ECI technology eliminates all single points of failure with full scalability; up to 32 modules in parallel and high efficiency of up to 96% in AC to AC conversion, and above 93.5% in DC/AC conversion, hence reducing operating costs. We can build the systems up to 2.7 MVA.

BRAVO is a compact and scalable modular inverter providing a pure sine wave AC supply. In conjunction with a DC Power system, it provides an excellent AC backup solution. It uses the latest inverter technology, providing superior energy efficiency in a compact size.

Applications

All business critical applications and all types of AC loads. The design is modular and scalable with hot- swappable inverter modules which ensures low Mean Time to Repair (MTTR), reduction in service costs and meets the changing needs for future expansion

Specification

Part number	T521730301
Efficiency (Typical): Enhanced power conversion / on line	96% / >93.5%
Dielectric strength DC/AC	4300 Vdc
Operating T° / Relative Humidity (RH) non-condensing	Tested according ETS300-019-2-3 Class 3.1 -20°C to 65°C, power de-rating from 40°C to 65°C / Max RH 95% for 96 hours per year
Storage T° / Relative Humidity (RH) non-condensing	Tested according ETS300-019-2-1 Class 1.2 -40°C to 70°C / Max RH 95% for 96 hours per year
AC Output power (VA) / (W)	3000 VA / 2400 W
Short time overload capacity	125% (15 seconds)
DC Input voltage: Nominal / range	48 VDC / (40-60V)*
Nominal current	53.2 A
Input Nominal voltage (AC)	230 V
Brownout	1600 W
Power factor	> 99%
Ac output Nominal voltage (AC**)	220 VAC - 240 VAC
Frequency	50 or 60 Hz
Nominal current	13 A
